PT80-PT100-PT120 yedekleri
Hypertherm ,Lincoln Electric ve ESAB yedek parçaları
Yoğun kullanıma sahip CNC plazma kesim yedek parçalarına ait kodlara ve gerekli bilgilere aşağıdaki tablolardan ulaşabilirsiniz
Ürün | Tanımlama | Kodu |
1 | PT-80 Hand Torch Head | 09800 |
1a | O-Ring | 51620.60 |
1b | Cooling Tube | 09800.42 |
1c | Wrench for electrode | 60368 |
2 | Handle with parts | 09705 |
3 | Electrode, Back Striking | 52558 |
4 | Swirl ring | 60027 |
5 | Tip ,Contact Cutting, ø 0.9, 30-40A, Back Striking | 51310.09 |
6 | Tip, Cutting, ø 1.0, 40-50A, Back Striking | 51311.10 |
| Tip, Cutting, ø 1.1, 50-60A, Back Striking | 51311.11 |
| Tip, Cutting, ø 1.2, 60-70A, Back Striking | 51311.12 |
| Tip, Cutting, ø 1.3, 70-80A, Back Striking | 51311.13 |
7 | Retaining Cap | 60510 |
8 | Double Pointed Spacer (for use with item 6 only) | 60434 |
9 | Contact Tip, ø 1.0, 40-50A, Back Striking | 51311S.10 |
| Contact Tip, ø 1.1, 50-60A, Back Striking | 51311S.11 |
| Contact Tip, ø 1.2, 60-70A, Back Striking | 51311S.12 |
| Contact Tip, ø 1.3, 70-80A, Back Striking | 51311S.13 |
10 | Tip, Gouging, 80A, Back Striking | 51311G.16 |
11 | Shield Cup Body | 60511 |
12 | Shield Cap, Hand | 60504 |
13 | Shield Cap, Gouging | 60508 |
Ürün | Tanımlama | Kodu |
1 | PT-100 Hand Torch Head | 09700 |
1a | O-Ring | 51190.41 |
1b | Cooling Tube | 09700.48 |
1c | Wrench for electrode | 60368 |
2 | Handle with parts | 09705 |
3 | Electrode, Back Striking | 52556 |
4 | Swirl ring, 30-70A | 60025 |
5 | Swirl ring, 80-100A and Gouging | 60026 |
6 | Tip, Contact Cutting, ø 0.9, 30-40A, Back Striking | 51245.09 |
7 | Tip, Cutting, ø 1.0, 40-50A, Back Striking | 51246.10 |
| Tip, Cutting, ø 1.1, 50-60A, Back Striking | 51246.11 |
| Tip, Cutting, ø 1.2, 60-70A, Back Striking | 51246.12 |
8 | Tip, Cutting, ø 1.4, 80-90A, Back Striking | 51248.14 |
| Tip, Cutting, ø 1.5, 100A, Back Striking | 51248.15 |
9 | Retaining Cap, 30-70A | 60500 |
10 | Retaining Cap, 80-100A | 60501 |
11 | Double Pointed Spacer (for use with item. 7 and 8 only) | 60444 |
12 | Contact Tip, ø 1.0, 40-50A, Back Striking | 51276.10 |
| Contact Tip, ø 1.1, 50-60A, Back Striking | 51276.11 |
| Contact Tip, ø 1.2, 60-70A, Back Striking | 51276.12 |
13 | Contact Tip, ø 1.4, 80-90A, Back Striking | 51278.14 |
| Contact Tip, ø 1.5, 100A, Back Striking | 51278.15 |
14 | Tip, Gouging, 100A, Back Striking | 51278G.22 |
15 | Shield Cup Body | 60502 |
16 | Shield Cap, Hand, 40-70A | 60504 |
17 | Shield Cap, Hand, 80-100A | 60505 |
18 | Shield Cap, Gouging | 60508 |
19 | Extended Electrode | 52556L |
20 | Extended Shielded Tip, ø 1.0, 40-50A, | 51276L.10 |
| Extended Shielded Tip, ø 1.1, 50-60A, | 51276L.11 |
| Extended Shielded Tip, ø 1.2, 60-70A, | 51276L.12 |
21 | Extended Shielded Tip, ø 1.4, 80-90A, | 51278L.14 |
| Extended Shielded Tip, ø 1.5, 100A, | 51278L.15 |
22 | Extended Shielded Cap, Hand, 40-70A | 60504L |
23 | Extended Shielded Cap, Hand, 80-100A | 60505L |
Ürün | Tanımlama | Kodu |
1 | ST-120 Hand Torch Head | 03800 |
1a | O-Ring | 02800.60 |
2 | Handle with Switch | 09705 |
2a | Switch | 07301.20 |
3 | Swirl ring, 40-80A | 60043E |
| Swirl ring, 40-80A Maximum Life | 60043 |
4 | Swirl ring, 80-120A | 60044E |
| Swirl ring, 80-120A Maximum Life | 60044 |
5 | Electrode, 40-80A | 52675 |
6 | Electrode, 80-120A | 52676 |
7 | Tip, Cutting, 40A | 51402 |
8 | Tip, Cutting, 60A | 51403 |
9 | Tip, Cutting, 80A | 51404 |
10 | Tip, Cutting, 100A | 51408 |
| Tip, Cutting, 120A | 51408T |
11 | Retaining Cap, 40-80A | 60493 |
12 | Retaining Cap, 80-120A | 60494 |
13 | Double Pointed Spacer | 60434 |
14 | Contact Tip, Cutting, 40A | 51405.10 |
| Contact Tip, Cutting, 60A | 51405.12 |
| Contact Tip, Cutting, 80A | 51405.14 |
15 | Contact Tip, Cutting, 100A | 51406 |
16 | Contact Tip, Cutting, 120A | 51406T |
17 | Shield Cup Body, 40-80A | 60495 |
18 | Shield Cup Body, 80-120A | 60496 |
19 | Shield Cap, Hand, 40-80A | 51981/TD |
20 | Shield Cap, Hand, 80-100A | 51983/TD |
21 | Shield Cap, Hand, 100-120A | 51988 |
22 | Contact Tip, Gouging, 100-120A | 51409.24 |
23 | Shield Cap, Gouging, 100-120A | 51989G |
